Hand Formable, NO molds needed make a part in 5 minutes.
Carbon Fiber & Steel Weights almost nothing Tougher than std Carbon Fiber - Too tough to crush, tear, or shatter
Fiber Steel an Instant Carbon Fiber /Steel product Formable Carbon Fiber /Steel Hybrid Material
No Molds
- Cut the sheets to your shape.
- Bend to your designs.
- Resin, rivet, add 3d printed parts, metal parts.
- Capable of being riveted before and after resin processing.
- Light & Strong even before Resin Processing
Materials Characteristics
- Conductive- The steel used is std carbon steel this s/b noted when riveting. The rivet point will become connected to the core and any other structure penetrating the core
- Materials sensitivity – Before resin introduction the core is moisture sensitive
- Minimum bend radius is 2 x material thickness ~ 0.1” on the inner curve
- Maximum flex repetition is 5 times with a 180º rotation ,at which point the core will begin to breakdown
Material Safety
- The metal core will cut skin so gloves must be worn that are tear proof
- Carbon Fiber can shed when shaped and unpacked, particle mask and gloves s/b used at all times
- If machining there will be carbon fiber dust so vacuum after working is required
Recommended Safety Data Sheet 439-3227-00SU-C000-12
